WPC floor production line
WPC wood-plastic flooring equipment is professional equipment used to produce wood-plastic composite (WPC) flooring. The main production process includes raw material mixing, extrusion molding, shaping and cooling, cutting and other steps.
产品详情
Main components:
Mixing system: Used to evenly mix PVC, calcium powder, and additives.
Extrusion system: The mixture is plasticized through a twin-screw extruder and extruded into shape.
Shaping system: Use vacuum shaping mold to shape the sheet.
Cooling bracket: Cool the shaped profiles to ensure stable size.
Traction system: Traction the sheet material
Cutting system: Cut the cooled and shaped profiles to a fixed length.
Palletizing system: Stack sheets of plates neatly according to requirements and quantity.
Product parameters:
model Model | Screw diameter (mm) Screw Diameter | Product thickness (mm) Sheet Width | Product width (mm) Sheet Width | Total power (KW) Total Power | Output (Kg/hr) Output | Overall size (mm) Outline Dimension | Equipment weight (Kg) Weight |
|---|---|---|---|---|---|---|---|
SWDJ-1 | 80/156 | 2-8 | 965/1220 | 120 | 300 - 400 | 19000×2200×3200 | 8500 |
SWDJ-2 | 92/188 | 2-8 | 965/1220 | 165 | 400 - 650 | 20500×2200×3300 | 13000 |
SWDJ-3 | 110/220 | 2-8 | 965/1220 | 245 | 800-1000 | 22000*2200*3500 | 2500 |
Equipment characteristics:
Efficient and energy-saving: Optimize design, reduce energy consumption, and improve production efficiency.
Environmentally friendly and pollution-free: Adopt an environmentally friendly dust collection system to reduce dust in the workshop, and no harmful substances are emitted during the production process.
High degree of automation: Achieve automated production and reduce labor investment.
Stable product quality: superior equipment performance ensures product size accuracy and surface quality.
Product advantages:
Environmentally friendly: Lightweight WPC flooring, full of feet, close to solid wood flooring, meets environmental requirements.
Durability: The material is stable, waterproof and moisture-proof, insect-proof, and long service life.
Machinability: It can be cut, nailed, bonded, etc., and it is convenient to process.
Decorative: It has wood texture, is beautiful and elegant, and can be customized in color.
The wood-plastic flooring produced by WPC wood-plastic flooring equipment is environmentally friendly, durable and beautiful, and is widely used in gardens, outdoor platforms, villas and other places.
