SPC floor production line
Technological innovation leads a new era of green building materials. In the field of modern architectural decoration, SPC stone plastic flooring has attracted much attention for its excellent performance and environmental protection characteristics, and the core supporting its quality lies in the advanced SPC stone plastic flooring five-roll production line equipment.
产品详情
SPC floor production line:
In the field of modern architectural decoration, SPC stone plastic flooring has attracted much attention for its excellent performance and environmental protection characteristics, and the core supporting its quality lies in the advanced SPC stone plastic flooring five-roll production line equipment.
Product parameters:
Model | Extruder Specifications | Product Thickness (mm) Sheet Thickness | Product width (mm) Sheet Width | Host power (KW) Main Motor Power | Total power (KW) Total Power | Output (Kg/hr) |
SWDB5-2 | 92/188 | 1.5-7 | 970-1220 | 90/110 | 270 | 600-800 |
SWDB5-3 | 110/220 | 1.5-7 | 970-1220 | 160/200 | 308/376 | 1100-1400 |
SWDB5-3-2 | 115/232 | 1.5-7 | 970-1220 | 200 | 400 | 1500-1800 |
SWDB5-3-3 | 125/243 | 1.5-7 | 970-1220 | 200 | 420 | 2000-2500 |
SWDB5-4 | 132/276 | 1.5-7 | 970-1220 | 280 | 500 | 2500-2900 |
SWDB5-5 | 150/300 | 1.5-7 | 970-1220 | 315 | 520 | 2900-3300 |
SWDB5-6 | 182/336 | 1.5-7 | 970-1220 | 450 | 650 | 3000-4000 |
Core advantages of the equipment: One-step multi-layer compounding, reducing costs and increasing efficiency
Multi-layer synchronization, efficient integration:
Surface color film decorative layer: Color films of various colors can be directly applied to achieve rich and diverse decorative effects without requiring secondary processing.
Hot compress on wear-resistant layer: Apply hot compress on the wear-resistant layer directly on the decorative layer of the plate to improve surface durability and reduce surface treatment equipment.
embossed texture: Through high-precision molds and hot pressing technology, three-dimensional embossed patterns such as imitation wood grains and stone grains are simultaneously pressed to meet individual needs.
Bottom layer: Synchronously hot compress cushion muffler layer, which effectively reduces noise and improves foot comfort.
The four major processes are completed simultaneously in the same production line, and multi-layer materials are closely combined, reducing labor and equipment investment and significantly reducing SPC floor production costs.
Imported servo control system:
The high-precision servo system regulates temperature, pressure, speed and other parameters in real time to ensure uniform extrusion and accurate fitting, and the error is controlled at the micron level.
The intelligent operating interface enables "one-click" automated production, simplifies processes and improves efficiency.
Environmentally friendly and energy-saving design:
Closed-loop temperature control system and energy-saving extruder reduce energy consumption and waste generation.
The entire glue-free hot pressing process ensures zero formaldehyde emission from products, complies with environmental protection regulations, and promotes green production.
Excellent performance of SPC stone plastic flooring: multiple advantages define quality benchmarks
Relying on the technical empowerment of the five-roll production line, SPC stone plastic floors are both functional and aesthetic, meeting the needs of diverse scenarios:
Environmentally friendly and recyclable: Natural stone powder is used as the core raw material, is free of formaldehyde and heavy metals, and can be recycled. The whole process is green and the ecology is protected.
Light, light and high load-bearing: Only 2 - 10mm thick and 4 - 10kg/㎡ weight, saving building space and load bearing, and no burden on renovation of old buildings。
Super wear-resistant and durable: The transparent wear-resistant layer on the surface has a wear-resistant speed of up to 6000 revolutions and a service life of 5 - 10 years. It is suitable for high-flow scenes such as hospitals, schools, and shopping malls.
Safety and anti-slip and fire prevention: The surface layer is specially anti-slip treatment, which has outstanding anti-slip performance; the fire protection rating reaches B1, self-extinguishing in case of fire and has no toxic smoke, and the safety performance is comparable to that of stone.
Waterproof, moisture-proof and milde-proof: vinyl resin substrate, 100% waterproof, non-mildew in humidity environments, suitable for use in humid areas such as kitchens and bathrooms.
Quiet, comfortable and impact-resistant: The bottom silencer layer effectively absorbs noise, the feet feel soft and resilient, and has excellent impact resistance. It recovers quickly after impact of heavy objects, reducing ground damage.
Efficient and seamless installation: The lock splicing is glue-free and can be used in 24 hours; the cutting and splicing is flexible, and the joints are small and almost seamless after strict construction, optimizing the visual effect.
Beautiful customization and diverse: Imitating wood grain, stone grain, carpet grain and other textures are realistic, supporting personalized color customization, and different material combinations release design creativity.
Acid, alkali and corrosion resistance: Adapt to harsh chemical environments such as hospitals and laboratories, and the surface is stable and free from damage.
Stable heat conduction and energy saving: uniform heat dissipation, small thermal expansion coefficient, suitable for floor heating environments, improving space comfort and energy efficiency.
Maintenance-free, long-lasting appearance: Just mop and clean it daily, and waxing it regularly to keep it as bright as new without special care.
Multi-dimensional protection in one: It integrates anti-slip, fire prevention, waterproof, mute, and impact resistance to meet the strict needs of multiple scenarios such as medical care, education, and business.
International certification trends: Through environmental certification in Europe, America and Asia Pacific, it is widely recognized by the market, and the domestic penetration rate continues to rise, with broad prospects.
Excellent elastic recovery: Unique material structure maintains high elastic recovery under the impact of heavy objects, and has no dent damage on the surface, extending service life.
Sustainable value chain: Environmentally friendly from production to use, materials can be recycled, helping low-carbon buildings and sustainable development.
Applications and prospects: Technology leads the market and empowers green buildings
SPC stone plastic floor five-roll production line equipment has helped companies achieve production capacity upgrades, and its products cover medical, education, commerce, residential and other fields. With environmental certification and excellent performance, SPC stone plastic flooring is gradually becoming the mainstream choice for floor decoration materials. In the future, with the advancement of green building policies and consumption upgrades, this equipment and products will continue to lead industry innovation and create a healthy, comfortable and beautiful space experience for humans.
